LED dance floor
LED dance floor
0_0002_led dance floor.jpg
LED dance floor (2).jpg
LED dance floor (1).jpg
LED dance floor (3).jpg
LED dance floor (4).jpg
LED dance floor (5).jpg
LED dance floor (6).jpg
LED dance floor (7).jpg

LED dance floor

Name LED Dance Floor screen
Pixel Pitch P2.5/P2.604/P2.976/P3.91/P4.81/P5.2/P6.25
Module Size 250*250*18mm
Cabinet Size 500*500*78mm/500*1000*78mm
Cabinet Matrial Steel
Cabinet weight 20kgs/cabinet&40kgs/cabinet
Brightness ≥1300 nits
Refresh Rate 3840&7680
Maintenance Way Front Access
Certification CE, FCC, ROHS, ISO
Name LED Dance Floor screen
    Contact us

    PRODUCT PARAMETERS

    Plxel P2.5 P2.604 P2.976 P3.91 P4.81 P5.2 P6.25
    Module composition
    Pixal composition SMD LED 1R
    1G,1B    		 SMD LED 1R
    1G,1B    		 SMD LED 1R
    1G,1B    		 SMD LED 1R
    1G,1B    		 SMD LED 1R
    1G,1B    		 SMD LED 1R
    1G,1B    		 SMD LED 1R
    1G,1B
    Pixel pitch(W"H)mm 2.5*2.5 2.604*2.604 2.976*2.976 3.91*3.91 4.81*4.81 5.2*5.2 6.25*6.25
    Module resolution(W*H) 100*100 96*96 84*84 64*84 52*52 48*48 40*40
    Module size(WH'D)mm 250*250*18 250*250*18 250*250*18 250*250*18 250*250*18 250*250*18 250*250*18
    Module weight(KG) 0.75  0.75  0.75  0.75  0.75  0.75  0.75
    Panel unit composition
    Contains modules gty(W*H) 2*2/2*4 2*2/2*4 2*2/2*4 2*2/2*4 2*2/2*4 2*2/2*4 2*2/2*4
    Pangl osalution(W*H 200*200
    200*400    		 192*192/
    192*384    		 168*168/
    168*336    		 128*128/
    128*256    		 104*104/
    104*208    		 96*96/96*192 80*80/80*160
    Pangl size(W"H*D)mm
    500*500*78/
    500*1000*78
    500*500*78/
    500*1000*78
    500*500*78/
    500*1000*78
    500*500*78/
    500*1000*78
    500*500*78/
    500*1000*78
    500*500*78/
    500*1000*78
    500*500*78/
    500*1000*78
    Resolution(dolm 160000  147456  112896  65536  43264  36864  25600
    Protection leval Indoor
    (front  IP54,
    back IP43)    		 Indoor
    (front  IP54,
    back IP43)    		 Indoor
    (front  IP54,
    back IP43)    		 Indoor
    (front  IP54,
    back IP43)    		    Indoor
    (front  IP54,
    back IP43)    		   Indoor
    (front  IP54,
    back IP43)    		 Indoor
    (front  IP54,
    back IP43)
    Panol flatness(mm ≤1 ≤1 ≤1 ≤1 ≤1 ≤1 ≤1
    White balance brightness(nits) Indoor≥1300 Indoor≥1300 Indoor ≥1300 Indoor≥1300 Indoor≥1300   Indoor ≥1300 Indoor≥1300
    Color temperature(K)
     6000—9300
     adjustable
      6000—9300
      adjustable
    6000—9300
    adjustable
    6000—9300
    adjustable
    6000—9300
    adjustable
    6000—9300
    adjustable
    6000—9300
    adjustable
    View angle() >120 >120 >120 >120 >120 >120 >120
    Electrical parameters
    Power consumption
    Alunit module)    		 DC6~7 DC6~7 DC6~7 DC6~7 DC6~7 DC6~7 DC6~7
    Peak power corsumption(Mmr)
    Awerage power
    consumption(Wmr)    		 800/300 800/300 800/300 800/300 800/300 800/300 800/300
    Power requirements AC220V AC220V AC220V AC220V AC220V AC220V AC220V
    Processing performance
    Dnve method Constant
    current drive    		   Constant
      current drive    		    Constant
     current drive    		 Constant
    current drive    		 Constant
    current drive    		 Constant
    current drive    		 Constant
    current drive
    Frame frequency(Hz) 50&60 50&60 50&60 50&60 50&60 50&60 50&60
    Refresh @60Hz
    frame signal input    		 ≥3840/≥7680 ≥3840/≥7680 ≥3840/≥7680 ≥3840/≥7680 ≥3840/≥7680 ≥3840/≥7680 ≥3840/≥7680
    Use parameters
    Life typical value(hrs) 100,000 100,000 100,000 100,000 100,000 100,000 100,000
    Work temperature('℃) -20-55 -20-55 -20-55 -20-55 -20-55 -20-55 -20-55
    Slorage temperature("C) -30-60 -30-60 -30-60 -30-60 -30-60 -30-60 -30-60
    Working humidity range(RH)
    without condensation    		 10-90% 10-90% 10-90% 10-90% 10-90% 10-90% 10-90%
    Defective ratio ≤4/100000 ≤4/100000 ≤4/100000 ≤4/100000 ≤4/100000 ≤4/100000 ≤4/100000
    Screen surface color Color consistency
    95%
    (white transparent
    or brown)    		 Color consistency
    95%
    (white transparent
    or brown)    		 Color consistency
    95%
    (white transparent
    or brown)    		 Color consistency
    95%
    (white transparent
    or brown)    		 Color consistency
    95%
    (white transparent
    or brown)    		 Color consistency
    95%
    (white transparent
    or brown)    		 Color consistency
    95%
    (white transparent
    or brown)
    nteraction Interactive/Non-
    interactive    		 Interactive/Non-
    interactive    		 Interactive/Non-
    interactive    		 Interactive/Non-
    interactive    		 Interactive/Non-
    interactive    		 Interactive/Non-
    interactive    		 Interactive/Non-
    interactive
